Input Voltage:
|
90-260V, 50-60 Hz
|
|
Led Source:
|
7x60W OSRAM RGBW 4-in-1 Quad-Color led
12x 3W (3in1 RGB) LED filament
|
|
Max Power :
|
550W
|
|
Protocol:
|
USITT DMX-512
|
|
Channels:
|
21/30/36/57/78/93CH, 6 channel mode optional
|
|
Pan movement:
|
540°(16bit fine)
|
|
Tilt movement:
|
270°(16bit fine)
|
|
Advanced moving system:
|
Scan position memory, auto reposition after unexpected movement
|
|
fast, stable and quiet, auto X-Y repositioning
|
|
Zoom Angle:
|
6°-45°
|
|
Strobe:
|
Variable from 1-25 flashes or random strobe
|
|
Control Mode
|
DMX512，Auto，RDM, Art-Net (Support for additional installation)
|
|
Dimming:
|
0-100% Smooth linear LED dimmer
Four dimming Curve (Linear/Square/I Sequare/Scurve) 0-100% linear dimming
|
|
Controls:
|
1.77" OLED display with 4 control buttons
|
|
|
display switch-off automatically after 60 seconds
|
|
Cooling System
|
Lower noise and efficient FAN cooling system
|
|
Power Connectors:
|
PowerCon＆#8482; compatible in/out power connectors
|
|
DMX Connectors:
|
3-pin DMX input/output (5-pin DMX is available)
|
|
Light Housing:
|
Durable plastic composite housing
|
|
Use
|
Indoor IP20 for stage, event, DJ shows, etc
|
|
More Function:
|
Each LED can be controlled individually. With unique honeycomb designed lens
|
|
High precision integrated structure PMMA lens, high transparency quartz glass light pipe, creating a softer dyeing range. Latest Aura filament pixel effect.
|
|
Color: RGBW color mixing with very bright and vibrant saturated colors, as well as soft pastels and white tones. Tungsten Emulation Option.Virtual Color Wheel.
|
|
Macro effects: Multiple built-in macros with control of foreground color, background color, speed and direction. 3D video mapping of fixture beam pixels and/or Aura filaments. High-speed pan, tilt and zoom
|
|
Temperature control: Intelligent temperature control, capable of automatically adjusting the speed of the cooling fan and overheating protection
|
|
Fan cooling (fan speed changed depends on temperature variation). Temperature detecting system (If the temperature detected error, the light doesn't work to protect the fixture).
|
